　　【一、air compressor：】

　　1、motor explosion-proof, explosion-proof grade exdiibt4, protection grade ip55

　　2、the motor has built-in heater (heating mode: when the motor is running, stop heating, when the motor stops running, it is in the heating state)

　　3、exdiibt6, protection grade ip56 for other electrical components in the air compressor

　　【increasing function：】

　　1、automatic stop (controlled by plc) : supply switch quantity, remote control and stop

　　2、bring rs485 communication interface

　　【nitrogen making machine：】

　　the carbon molecular sieve is used for the pressure of psa)

　　complete machine explosion-proof grade exdiibt6

　　【product gas technology index：】

　　【nitrogen gas flow：】5-500nm3/h(the normal temperature、101.325kpa)

　　【nitrogen gas purity：】≥95%~99.995%

　　【nitrogen gas dew point：】-38℃ ～-50℃

　　【the nitrogen gas outlet pressure：】≤ 0.2～0.6mpa(adjustable)

　　【special customized：】0.05~6.0mpa(customizable)

　　【the tri-yang series psa system is divided into nitrogen：97% 、98%、99%、99.5%、99.9%、99.95%、99.99%、99.99%、99.995% ，you can choose。】

　　【the main components of the nitrogen equipment：】air post-treatment purification system, air cushion tank, variable pressure adsorption host system and nitrogen buffer tank and control system.

　　【there are two basic conditions for nitrogen production：】 1、the compressed air       2、the power supply

　　【air post-treatment purification system：】it is composed of freeze-drying machine, except water, oil removal, dust removal and fine filter, automatic drainer.

　　【freeze drying machine action：】freeze drying used to except the water cooling air, the purification of the compressed air pressure dew point 2-10 ℃, oil removal rate was 99.999%, and the dust particles & le; 0.01 u, make sure the absorbent work is not contaminated. provide adequate protection for carbon molecular sieve to ensure the life of carbon molecular sieve.

　　【air cushion action：】improve the continuity of the output flow and the stability of the pressure。

　　【the adsorption and adsorption system of nitrogen was adsorbed：】it consists of a, b adsorption tower, pneumatic valve, unqualified emptying and instrument control system.

　　the two adsorption towers are alternately adsorbed and regenerated to complete nitrogen and oxygen separation, and output nitrogen continuously。

　　【automatic control system：】the main is programmable plc controller, indicating instrument, purity analysis online display, unqualified alarm.

　　【nitrogen buffer tank：】composed of nitrogen buffer tank and output regulating valve. function: nitrogen injection into nitrogen buffer can be supplied by the system output by the host system to ensure the continuous supply of nitrogen and the output of the regulating valve. the pressure size can be adjusted by the pressure reducing valve.
